Firefighting Pump Sets (TF-FFS). Proposed catalog envelope: 50–5,000 gpm (11–1,136 m³/h); 50–250 m / ~5–25 bar. Final selection is project-specific.
| Model | TF-FFS |
|---|---|
| Pump Type | Packaged firefighting pump set with main pump(s), jockey pump and controls |
| Nominal Size Range | Typical 2 in to 12 in; larger engineered |
| Flow Range | 50–5,000 gpm (11–1,136 m³/h) |
| Head | 50–250 m / ~5–25 bar |
| Pressure Rating | Selected to fire-system duty |
| Temperature | Ambient clean fire-water |
| Connection | Flanged suction/discharge manifolds |
Casing: Cast iron / ductile iron / carbon steel depending pump; Impeller: Bronze / stainless steel; Shaft: Stainless/alloy steel
Final metallurgy, shaft material, wear components, elastomers and seal arrangement are selected to suit the pumped liquid, temperature, pressure and project specification.
NFPA 20 configuration available; UL/FM only when specifically quoted/applicable; Local fire-code requirements
Compliance, listing or certification applies only when specifically included in the selected model and quotation.
Documents are published when available for the selected configuration.
TF-FFS is a TexasFlow series for fire water, buildings, industrial applications.
Selection note: Published ranges are proposed catalog envelopes. Final model, duty point, NPSHr, motor power, pressure class, metallurgy and certification must be confirmed against approved manufacturer data.
| Size | Typical 2 in to 12 in; larger engineered |
|---|---|
| Pressure Rating | Selected to fire-system duty |
| Material | Casing: Cast iron / ductile iron / carbon steel depending pump; Impeller: Bronze / stainless steel; Shaft: Stainless/alloy steel |
| Standard | NFPA 20 configuration available; UL/FM only when specifically quoted/applicable; Local fire-code requirements |
| Flow Rate | 50–5, 000 gpm (11–1, 136 m³/h) |
| Head | 50–250 m / ~5–25 bar |
| Connection Type | Flanged suction/discharge manifolds |
| Temperature | Ambient clean fire-water |
